Please Contact Us to Order to offer best price and delivery time for Carlo Gavazzi - CTD11H10005AXXX Current Transformer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Carlo Gavazzi - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy CTD11H10005AXXX by Carlo Gavazzi in United States?
You can purchase CTD11H10005AXXX by Carlo Gavazzi from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the CTD11H10005AXXX?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in United States?
While we are not the official distributor or seller of Carlo Gavazzi in United States, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access CTD11H10005AXXX catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CTD11H10005AXXX on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CTD11H10005AXXX?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Carlo Gavazzi |
| Product | CTD11H10005AXXX |
| Description | Current Transformer |
| Internal code | ONR241801 |
| Weight | 1 |
| Technical specification | AC Solid-core Current Transformer Type CTD-11V/11H (max 35x125mm) • Bus-bar type solid-core current transformer • Accuracy class 0.5 • Current range from 1000 to 4000A • Up to 8 bus-bar fixing screws • Double screw terminals (up to 4-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-11V4000 5AXXX Solid-core current trans- former with bus-barmount- ing facility. Rated primarycurrentfrom 1000 to 4000A. Model Primary current Secondary current Option Type Selection Model CTD-11V:vertical mounting CTD-11H:horizontal mounting Primary current 1000 1500 2000 2500 3000 4000 Secondary current 5A Option XXX:none InputSpecifications Operating frequency50-60 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class B Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-timethermal current Ith is anyway limited by the cable/bus-bar size Security factor (FS)≤ 10 General Specifications Working temperature-30°C to +40°C (-22°F to 104°F) (R.H. < 90% non condensing @ 40°C) Storage temperature -30°C to +70°C (-22°F to 158°F) (R.H. < 90% non condensing @ 40°C) Approvals CE Connection Screw type Cable cross section area From 1.5 to 4 mm2 Protection degreeIP20 Bus-bar size Max. 35x125 mm Weight < 1.2 Kg Standards Accordingto EN60044-1 Housing Polycarbonate UL94 V2 Mounting Bus-bar mounting Standard accessories Two terminal block screws. Eight bus-bar fixing screws. Two sealable terminal block covers. Output Specifications Rated secondary current5 A Burden15 VA Specifications are subject to change without noticeCTD-11VH DS ENG 2503111 |
