Please Contact Us to Order to offer best price and delivery time for Carlo Gavazzi - CTD1X505AXXX Current Transformer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Carlo Gavazzi - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy CTD1X505AXXX by Carlo Gavazzi in United States?
You can purchase CTD1X505AXXX by Carlo Gavazzi from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the CTD1X505AXXX?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in United States?
While we are not the official distributor or seller of Carlo Gavazzi in United States, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access CTD1X505AXXX catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CTD1X505AXXX on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CTD1X505AXXX?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Carlo Gavazzi |
| Product | CTD1X505AXXX |
| Description | Current Transformer |
| Internal code | ONR241837 |
| Weight | 1 |
| Technical specification | AC Current Transformer (max 23mm φ cable) Type CTD-1X • Cable and bus-bar type current transformer • 0.5 class, currents from 50 to 300 A • Removable DIN-rail mounting holder • Removable panel fixing clips • 2 cable/bus-bar isolated fixing screws • Double screw terminals (up to 8-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-1X 100 5A XXX Cable/Bus-bar type current transformer with DIN-rail/bus- bar and panel mounting facility. Type Selection Primary current From 50 to 300A (Refer to Range Table) Rated primary currents from 50 A to 300 A. Secondary current 1A 5A Model Primary current Secondary current Option Optional fixing kit: CTD-kit Option XXX:none XTX: tropicalization InputSpecifications Operating frequency48 to 62 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class E (max 75°C) Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-timethermal current Ith is anyway limited by the cable/bus-bar size Extended current rating 120% Security factor (FS)≤ 5 (Class: 0.5, 1 and 3) General Specifications StandardsAccording to EN60044-1 Housing ABS, self-extinguishing: UL 94 V-0 Mounting DIN-rail bus-bar and panel mounting Standard accessoriesTwo terminal block screws. Two sealable terminal block covers. Two panel mounting fixing clips. One DIN rail adapter. Optional accessories Extended fixing kit CTD-kit: Six cable/bus-bar fixing screws. Six plastic caps for cable/bus-bar fixing screws. Two panel mounting fixing clips. Special features1 A secondary current, Tropicalization Working temperature -25°C to +60°C (-13°F to 140°F) (R.H. < 90% non condensing @ 40°C) Storage temperature-30°C to +70°C (-22°F to 158°F) (R.H. < 90% non condensing @ 40°C) ApprovalsCE, cUrus and CSA ConnectionScrew type Cable cross section area From 1.5 to 6 mm2 Min/Max screws tightening torque relevant to terminal block screws: From 1 to 2 Nm Max screws tightening torque relevant to the cable/bus-bar fixing screws: 0,3 Nm Protection degree IP00 IP20 (with sealable terminal block covers + wire termi nals) Cable diameterMax. 23 mm Bus-bar sizeMax. 20x5 mm WeightFrom 150 to 200 g Output Specifications Rated secondary current5 A or 1 A |
