Please Contact Us to Order to offer best price and delivery time for Carlo Gavazzi - CTD2X6005AXXX AC Current Transformer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Carlo Gavazzi - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy CTD2X6005AXXX by Carlo Gavazzi in United States?
You can purchase CTD2X6005AXXX by Carlo Gavazzi from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the CTD2X6005AXXX?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in United States?
While we are not the official distributor or seller of Carlo Gavazzi in United States, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access CTD2X6005AXXX catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CTD2X6005AXXX on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CTD2X6005AXXX?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Carlo Gavazzi |
| Product | CTD2X6005AXXX |
| Description | AC Current Transformer |
| Internal code | ONR241858 |
| Weight | 1 |
| Technical specification | AC Current Transformer (max 30x10mmbus-bar) Type CTD-2X • Bus-bar type current transformer • 0.5 class, currents from 40 to 600 A • Integrated DIN-rail mounting holder • Removable panel fixing clips • 2 Bus-bar isolated fixing screws • Double screw terminals (up to 8-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-2X 200 5A XXX Cable/Bus-bar type current transformerwith DIN-rail/bus- bar and panel mounting facili- Type Selection ty. Rated primary currents from 40 A to 600 A. Model Primary current Secondary current Option Optional fixing kit: CTD-kit Primary current From 40 to 600A (Refer to Range Table) Input Specifications Secondary current 1A 5A Option XXX:none XTX:tropicalization Operating frequency45 to 65 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class E (max 75°C) Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-time thermal current Ith is anyway limited by the cable/ bus-bar size Extended current rating 120% Security factor (FS)≤ 5 (Class: 0.5, 1 and 3) General Specifications Standards According to EN60044-1 HousingABS, self-extinguishing: UL 94 V-0 MountingDIN-rail bus-bar and panelmounting Standard accessoriesTwo terminal blockscrews. Two cable/bus-bar fixingscrews. Two sealable terminal block covers. Two panelmounting fixingclips. Two plastic caps for cable/bus-bar fixingscrews. Optional accessoriesExtended fixing kit: CTD-kit Two panel mounting fixing clips. Six cable/bus-bar fixing screws. Six plastic caps for cable/bus-bar fixing screws. Special features 1 A secondary current, Tropicalization Working temperature-25°Cto +60°C (-13°F to 140°F) (R.H.< 90% non condensing @ 40°C) Storage temperature -30°Cto +70°C (-22°F to 158°F) (R.H.< 90% non condensing @ 40°C) Approvals CE, cUrus and CSA Connection Screw type Cablecrosssection areaFrom1.5 to 6 mm2 Min/Max screws tightening torque relevant to terminal blockscrews: From1 to 2 Nm Max screws tightening torque relevant to the cable/bus-bar fixingscrews: 0,3 Nm Protection degreeIP00 IP20(withsealable terminal block covers + wire terminals) Cablediameter Max. 24 mm Bus-bar size HorizontalMax. 32x5 30x10 25x20 mm Vertical Max. 25x12mm Weight From350 to 500 g |
