Please Contact Us to Order to offer best price and delivery time for Carlo Gavazzi - DBA02CM24 UNCTION Delay on release OUTPUT SIGNAL 1 number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Carlo Gavazzi - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy DBA02CM24 by Carlo Gavazzi in United States?
You can purchase DBA02CM24 by Carlo Gavazzi from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the DBA02CM24?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in United States?
While we are not the official distributor or seller of Carlo Gavazzi in United States, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access DBA02CM24 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DBA02CM24 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DBA02CM24?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Carlo Gavazzi |
| Product | DBA02CM24 |
| Description | UNCTION Delay on release OUTPUT SIGNAL 1 |
| Internal code | ONR247406 |
| Weight | 1 |
| Technical specification | Delay on Release Types DBA02, PBA02 • Time range 0.1 s to 100 h • Knob selection of time range • Knob-adjustable time setting • Repeatability: ≤ 0.2% • Output: 8 A SPDT relay • For mounting on DIN-rail in accordance with DIN/EN 50 022 or Plug-in • 22.5 mm Euronorm or 36 mm Plug-in module housing • Combined AC and DC power supply • LED indication for relay status and power supply ON DBA02 PBA02 Product Description Ordering Key DBA 02 C M24 Multi-voltage delay on release timer with 7 knob selectable time ranges with- in 0.1 s and 100 h. For Type Selection mounting on DIN-rail (DBA02) or Plug-in (PBA02). Housing Function Type Item number Output Power supply Mounting Output Housing Supply: 24 VDC and 24 to 240 VAC DIN-rail SPDT D-Housing DBA 02 C M24 Plug-in SPDT P-Housing PBA 02 C M24 Time Specifications Output Specifications Time ranges Knob Selectable 0.1 to 1 s 1 to 10 s 6 to 60 s 60 to 600 s 0.1 to 1 h 1 to 10 h 10 to 100 h Setting accuracy ≤ 5% Repeatability ≤ 0.2% Time variation Within rated power supply ≤ 0.05%/V Within ambient temperature ≤ 0.2%/ºC Reset Manual reset of time and/or relay Close the trigger contact between pins A1 and Y1 or 2 and 5 Pulse duration ≥ 100 ms Power supply interruption ≥ 200 ms Output SPDT relay Rated insulation voltage 250 VAC (rms) Contact Ratings (AgSnO2) µ Resistive loads AC 1 8 A @ 250 VAC DC 12 5 A @ 24 VDC Small inductive loads AC 15 2.5 A @ 250 VAC DC 13 2.5 A @ 24 VDC Mechanical life ≥ 30 x 106 operations Electrical life ≥ 105 operations (at 8 A, 250 V, cos ϕ = 1) Operating frequency < 7200 operations/h Dielectric strength Dielectric voltage 2 kVAC (rms) Rated impulse withstand volt. 4 kV (1.2/50 µs) Supply Specifications Power supply Overvoltage cat. III Rated operational voltage (IEC 60664, IEC 60038) through terminals: (DBA01C) A1, A2 24 VDC ±15% and (PBA01C) 2, 10 24 to 240 VAC +10%/-15%, 45 to 65 Hz Voltage interruption ≤ 10 ms Rated operational power AC supply 4 VA DC supply 1.5 W Specifications are subject to change without notice (20.07.07) 1 |
