Please Contact Us to Order to offer best price and delivery time for Carlo Gavazzi - DBB02CM24 FUNCTION True delay on release OUTPUT SIGNAL 1 number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Carlo Gavazzi - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy DBB02CM24 by Carlo Gavazzi in United States?
You can purchase DBB02CM24 by Carlo Gavazzi from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the DBB02CM24?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in United States?
While we are not the official distributor or seller of Carlo Gavazzi in United States, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access DBB02CM24 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DBB02CM24 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DBB02CM24?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Carlo Gavazzi |
| Product | DBB02CM24 |
| Description | FUNCTION True delay on release OUTPUT SIGNAL 1 |
| Internal code | ONR247412 |
| Weight | 1 |
| Technical specification | True delay onrelease Types DBB02, PBB02 • Time range 60 s to 10 h - battery powered • 3 time ranges selectable by DIP-switches • Knob-adjustable time setting • Automatic start after drop-out of power supply • Repeatability: ≤ 0.2% • Output: 8 A SPDT or 8 A DPDT relay • For mounting on DIN-rail in accordance with DIN/EN 50 022 or Plug-in • 22.5 mm Euronorm or 36 mm Plug-in module housing • Combined AC and DC power supply • LED indication for power supply ON DBB02 PBB02 Product Description Ordering keyDBB 02 C M24 Multivoltagetrue delay on release timer with 3 time ranges from 60 s to 10 h selectable by DIP-switches. Thebuilt-in battery(NiCd) willbechargedwhilethe power supply is applied. For mounting on DIN-rail (DBB02) or Plug-in (PBB02). Housing Function Type Item number Output Power Supply Type Selection MountingOutputHousingSupply: 24 to 240 VAC/DC For DIN-railSPDTD - Housing DBB 02 C M24 DPDTD - Housing DBB 02 D M24 Plug-in SPDTP - HousingPBB 02 C M24 DPDTP - HousingPBB 02 D M24 TimeSpecifications Time ranges Selectable by DIP-switches 60to600 s 0.1 to1 h 1to10 h Repeatability ≤ 0.2% Time variation Within rated battery voltage ≤ 1% Within rated power supply ≤ 0.05% Within ambient temperature ≤ 0.2% ResetPower supply applied for min. 200 ms Output Specifications OutputSPDT or DPDT relay Rated insulation voltage250 VAC (RMS) Contact Ratings(AgNi) µ Resistive loadsAC 1 8 A @250 VAC DC 12 5 A @24 VDC Small inductive loadsAC 15 2.5 A@250 VAC DC 13 2.5 A@24 VDC Mechanical life≥ 2 x 106operations Electrical lifeAC 1 ≥ 105operations (at 8 A, 250 V, cos ϕ = 1) Operating frequency< 3600 operations / h Dielectric strength Dielectric voltage2 kVAC (RMS) Rated impulse withstand voltage4 kV (1.2/50∝s) Supply Specifications Power supplyOvervoltage cat. III Rated operational voltage(IEC 60664, IEC 60038) through terminals: (DBB02) A1, A2 24 to 240 VAC/DC (PBB02)2, 10 +10% -15%, 45 to 65 Hz Voltage interruption≤ 40 ms Rated operational power AC supply: 3.7 VA DC supply: 1.3 W Built-in battery for time function Nominal voltage4.8 VDC Min./max. battery voltage 4.2 VDC/6.2 VDC Charging current 2 mA Discharging current0.5 mA Capacity 80 mA/h Specifications are subject to change without notice (15.04.10)1 |
