Please Contact Us to Order to offer best price and delivery time for Carlo Gavazzi - DFB01CM24 OUTPUT SIGNAL 1 relay SETPOINTS 2, adjustable MONITORED number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Carlo Gavazzi - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy DFB01CM24 by Carlo Gavazzi in United States?
You can purchase DFB01CM24 by Carlo Gavazzi from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the DFB01CM24?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in United States?
While we are not the official distributor or seller of Carlo Gavazzi in United States, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access DFB01CM24 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DFB01CM24 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DFB01CM24?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Carlo Gavazzi |
| Product | DFB01CM24 |
| Description | OUTPUT SIGNAL 1 relay SETPOINTS 2, adjustable MONITORED |
| Internal code | ONR249728 |
| Weight | 0.14 |
| Technical specification | Monitoring Relays Frequency Monitoring Types DFB01, PFB01 DFB01 PFB01 • Over/under frequency monitoring relays • Measuring if power supply frequency is within set limits • Measure on own power supply • Measuring ranges Voltage: 24 to 240 VAC Frequency: 50 - 60 Hz • Separately adjustable upper/lower level on relative scale • Adjustable delay on alarm or on recovery (0.1 to 30 s) • Programmable latching or inhibit at set level • Output: 8 A SPDT relay N.D. or N.E. selectable • For mounting on DIN-rail in accordance with DIN/EN 50 022 (DFB01) or plug-in module (PFB01) • 22.5 mm Euronorm housing (DFB01) or 36 mm plug-in module (PFB01) • LED indication for relay, alarm and power supply ON Product Description Ordering key DFB 01 C M24 DFB01 and PFB01 are pre- cise frequency monitoring relays. The relays monitor their own power supply from 24 to 240 VAC. The advantage of using the latch function isthat the relay can be kept energized even after the end of the alarm condition. Inhibit func- tion can be used to avoid relay operation when not desired(maintenance, tran- sitions). The LED's indicate thestateofthealarm and the output relay. Housing Function Type Item number Output Power Supply Type Selection Mounting OutputMeasuring rangeSupply: 24 to 240 VAC DIN-rail SPDT50-60 HzDFB 01 C M24 Plug-inSPDT50-60 HzPFB 01 C M24 InputSpecificationsOutput Specifications Input Own power supplyDFB01: A1, A2 (24 to 240 VAC) PFB01: 2, 10 (24 to 240 VAC) Measuring ranges Upper levelLower level Selectable by DIP-switches 2 Hz range-0.2 to +2 Hz-2 to +0.2 Hz 50 Hz 49.8 to 52 Hz48 to 50.2 Hz 60 Hz 59.8 to 62 Hz58 to 60.2 Hz 10 Hz range-1 to +10 Hz -10 to +1 Hz 50 Hz49 to 60 Hz 40 to 51 Hz 60 Hz59 to 70 Hz 50 to 61 Hz Contact input DFB02Terminals Z1, Z2 PFB02Terminals 8, 9 Disabled > 10 kΩ Enabled< 500 Ω Pulse width > 500 ms Hysteresis OutputSPDT relay Rated insulation voltage250 VAC Contact ratings (AgSnO2)µ Resistive loadsAC 1 8A @ 250 VAC DC 12 5 A @ 24 VDC Small inductive loads AC 15 2.5 A @ 250 VAC DC 13 2.5 A @ 24 VDC Mechanical life≥ 30 x 106 operations Electrical life ≥ 105 operations (at 8 A, 250 V, cos ϕ = 1) Operating frequency≤ 7200 operations/h Dielectric strength Dielectric voltage≥ 2 kVAC (rms) Rated impulse withstand volt.4 kV (1.2/50 µs) 2 Hz range~ 0.05 Hz 10 Hz range~ 0.25 Hz |
