Please Contact Us to Order to offer best price and delivery time for Carlo Gavazzi - DFC01DB23 OUTPUT SIGNAL 2 relays SETPOINTS 2, adjustable MONITORED VARIAB number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Carlo Gavazzi - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy DFC01DB23 by Carlo Gavazzi in United States?
You can purchase DFC01DB23 by Carlo Gavazzi from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the DFC01DB23?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in United States?
While we are not the official distributor or seller of Carlo Gavazzi in United States, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access DFC01DB23 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DFC01DB23 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DFC01DB23?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Carlo Gavazzi |
| Product | DFC01DB23 |
| Description | OUTPUT SIGNAL 2 relays SETPOINTS 2, adjustable MONITORED VARIAB |
| Internal code | ONR249733 |
| Weight | 1 |
| Technical specification | Monitoring Relays Frequency monitoring TypeDFC01 • Over and under frequency monitoring relay • Measures if power supply frequency is within set limits • Measures on own power supply • Separately adjustable upper/lower level on relative scale • Separately adjustable delay functions (0.1 to 30 s) • Output: 2 x 8 A SPDT relays • For mounting on DIN-rail in accordance with DIN/EN 50 022 • 45 mm Euronorm housing • LED indication for relays, alarm and power supply ON Product Description Ordering key DFC 01 D B23 DFC01 is a precise frequen- cy monitoring relay. It moni- tors its own power supply. Overfrequencyandunder- frequency can be monitored separately with two indepen- dentsetpoints,delay times and relay outputs. The LED's indicate the state of the alarm and the output relay. Housing Function Type Item number Output Power Supply TypeSelection MountingOutput Supply: 24/48 VACSupply: 115/230 VAC DIN-rail2 x SPDT DFC 01 D B48DFC 01 D B23 InputSpecifications Input Own power supply A1, A2 or A2, A3 Measuring ranges Upper level Lower level Selectable by DIP-switches 2 Hz range+0.2 to +2.2 Hz -2.2 to -0.2Hz 50 Hz 50.2 to 52.2 Hz 47.8 to 49.8 Hz 60 Hz 60.2 to 62.2 Hz 57.8 to 59.8 Hz 10 Hz range+1 to +11 Hz-11 to -1 Hz 50 Hz 51 to 61 Hz39 to 49 Hz 60 Hz 61 to 71 Hz49 to 59 Hz Ranges Upper frequency level+10 to +110% of the selected range Lower frequency level-110 to -10% of the selected range Output Specifications Output2 x SPDT relays N.E. Rated insulation voltage 250 VAC Contact ratings (AgSnO2)µ Resistive loadsAC 1 8 A @ 250 VAC DC 12 5 A @ 24 VDC Small inductive loads AC 15 2.5 A @ 250 VAC DC 13 2.5 A @ 24 VDC Mechanical life≥ 30 x 106operations Electrical life ≥ 105operations (at 8 A, 250 V, cos ϕ = 1) Operating frequency≤ 7200 operations/h Dielectric strength Dielectric voltage≥ 2 kVAC (rms) Rated impulse withstand volt.4 kV (1.2/50 µs) Hysteresis (frequency) 2 Hz range~ 0.05 Hz 10 Hz range~ 0.25 Hz Supply Specifications Power supplyOvervoltage cat. III Rated operational voltage(IEC 60664, IEC 60038) through terminals:A1, A2 or A3, A2 B48:24/48 VAC ± 15% 40 to 70 Hz, insulated B23:115/230 VAC ± 15% 40 to 70 Hz, insulated Rated operational power 5 VA |
