Please Contact Us to Order to offer best price and delivery time for Omega - LC321-750 MINIATURE COMPRESSION LOAD CELL number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Omega - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy LC321-750 by Omega in United States?
You can purchase LC321-750 by Omega from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the LC321-750?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Omega in United States?
While we are not the official distributor or seller of Omega in United States, we source our products from reliable channels and offer you original Omega equipment at competitive prices.
How can I access LC321-750 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for LC321-750 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for LC321-750?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Omega |
| Product | LC321-750 |
| Description | MINIATURE COMPRESSION LOAD CELL |
| Internal code | ONR5127074 |
| Technical specification | 750 lbf, ± 2.00%, Linearity, 2 mV/V Output, Cable 5-Point Calibration 0%, 50%, 100%, 50%, 0% Accuracy ± 2 %, ± 5% with transitional flow Cable Length 5 ft Calibration Option 5 POINT NIST Electrical Connection Cable Electrical Output 2 mV/V Enclosure Ratings IP65 Force Type Compression Height 0.4 in Hysteresis ± 2.0% Input Resistance 360 Ω min Linearity ± 2.0% Load Cell Capacity 750 lbF Load Cell Type Pancake Materials Stainless Steel Operating Temperature, Max 121 °C Operating Temperature, Min -54 °C Outer Diameter 1.5 in Output Resistance 350 ± 5 Ω Overload, Max 300% FS Process Temperature, Max 71 °C Process Temperature, Min 16 °C Repeatability ± 2.0% Safe Overload 150% FS Supply Power Note 10 Vdc, 15 Vdc maximum Supply Voltage 10 Vdc Thermal Span Effect 0.010% rdg/°F Thermal Zero Effect 0.005% FSO/°F Through Hole Thread 1/4"-28 UNF Wiring/Connector Table Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input Zero/Balance Error ± 2% load-cell-capacity 750 lbF |
